Zyxel XS3700-24 [168/371] Local switch lldp information on a port
![Zyxel XS3700-24 [168/371] Local switch lldp information on a port](/views2/1168986/page168/bga8.png)
Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
168
This example shows local Switch (the Switch you’re accessing) LLDP information on a port.
The following table describes the labels in this screen.
sysname# show lldp info local interface port-channel 2
LLDP Local Device Information Detail:
Local Port: 2
Port ID Subtype: local-assigned
Port ID: 2
Port Description:
Extended TLV Info 802.1 OUI (hex value) = 00-80-c2
-Port VLAN ID
-ID: 1
-DCBX Application Priority
- ether-type: fcoe Priority: 2
-DCBX ETS Configuration
-Willing Bit: False
-Max Traffic Classes: 3
-Priority-Group 2: Strict-priority, Priority-list:7
-Priority-Group 1: ETS Bandwidth 50%, Priority-list:3-6
-Priority-Group 0: ETS Bandwidth 50%, Priority-list:0-2
-DCBX PFC Configuration
-Willing Bit: True
-PFC capability: 8
-Priority enable list: 0-2
Extended TLV Info 802.3 OUI (hex value) = 00-12-0f
-MAC PHY Configuration & Status
-AN Supported: Y
-AN Enabled: Y
-AN Advertised Capability: 1000baseTFD
-Oper MAU type: 30
-Link Aggregation
-Capability: Y
-Status: N
-Port ID: 2
-Max Frame Size
-Frame Size: 1518
--------------------------------------------------
sysname#
Table 112 Local Switch LLDP information on a port
LABEL DESCRIPTION
LLDP Local Device
Information Detail
This displays the local port, port ID, and port description.
Port VLAN ID This displays the VLAN ID for this port.
DCBX Application
Priority
This displays the priority given to FCoE traffic on the Switch.
DCBX ETS
Configuration
This displays the Willing Bit, Max Traffic Classes, and Traffic Class binding
for each priority.
DCBX PFC
Configuration
This displays the Willing Bit, PFC capability, and priority enable list.
MAC PHY Configuration
& Status
This displays the AN Supported, AN Enabled, AN Advertised Capability,
Oper MAU type
