Ethernet Switch CLI Reference Guide
245
CHAPTER 65
Remote Management
Commands
Use these commands to specify a group of one or more “trusted computers” from which an
administrator may use one or more services to manage the Switch and to decide what services
you may use to access the Switch.
65.1 Command Summary
The following table describes user-input values available in multiple commands for this
feature.
The following section lists the commands for this feature.
Table 154 remote-management User-input Values
COMMAND DESCRIPTION
index 1-4
Table 155 remote-management Command Summary
COMMAND DESCRIPTION M P
show remote-management [index] Displays all secured client information or, optionally, a specific
group of secured clients.
E3
remote-management <index> Enables the specified group of trusted computers. C 13
no remote-management <index> Disables the specified group of trusted computers. C 13
remote-management <index> start-
addr <ip> end-addr <ip> service
<[telnet] [ftp] [http] [icmp]
[snmp] [ssh] [https]>
Specifies a group of trusted computer(s) from which an
administrator may use the specified service(s) to manage the
Switch. Group 0.0.0.0 - 0.0.0.0 refers to every computer.
C13
no remote-management <index>
service <[telnet] [ftp] [http]
[icmp] [snmp] [ssh] [https]>
Disables the specified service(s) for the specified group of
trusted computes.
C13
Table 156 service-control Command Summary
COMMAND DESCRIPTION M P
show service-control Displays service control settings. E 3
service-control console
<timeout>
Defines the timeout period (in minutes) for a management
session via the console port.
C13
service-control ftp Allows FTP access to the Switch. C 13
