Ethernet Switch CLI Reference Guide
243
CHAPTER 64
RADIUS Commands
Use these commands to configure external RADIUS (Remote Authentication Dial-In User
Service) servers.
64.1 Command Summary
The following section lists the commands for this feature.
Table 152 radius-server Command Summary
COMMAND DESCRIPTION M P
show radius-server Displays RADIUS server settings. E 3
radius-server host <index> <ip>
[auth-port <socket-number>] [key
[cipher] <key-string>]
Specifies the IP address of the RADIUS authentication server.
Optionally, sets the UDP port number and shared secret.
index: 1 or 2.
cipher: inform the Switch that the string after the word
"cipher" is an encrypted secret. This is used in password
encryption. To encrypt the password, use the password
encryption command.
key-string: 1-32 alphanumeric characters.
C14
radius-server mode <index-
priority|round-robin>
Specifies how the Switch decides which RADIUS server to
select if you configure multiple servers.
index-priority: The Switch tries to authenticate with the
first configured RADIUS server. If the RADIUS server does
not respond, then the Switch tries to authenticate with the
second RADIUS server.
round-robin: The Switch alternates between RADIUS
servers that it sends authentication requests to.
C14
radius-server timeout <1-1000> Specify the amount of time (in seconds) that the Switch waits
for an authentication request response from the RADIUS
server.
In index-priority mode, the timeout is divided by the
number of servers you configure. For example, if you
configure two servers and the timeout is 30 seconds, then the
Switch waits 15 seconds for a response from each server.
C14
no radius-server <index> Resets the specified RADIUS server to its default values. C 14
Table 153 radius-accounting Command Summary
COMMAND DESCRIPTION M P
show radius-accounting Displays RADIUS accounting server settings. E 3
radius-accounting timeout <1-
1000>
Specifies the RADIUS accounting server timeout value. C 13
