Chapter 91 Voice VLAN Commands
Ethernet Switch CLI Reference Guide
321
91.3 Command Example
This example configures Voice VLAN to port number 5, priority level number 6 and displays
Voice VLAN session.
sysname# configure
sysname(config)# voice-vlan 5
sysname(config)# voice-vlan priority 6
sysname(config)# exit
sysname# show voice-vlan
Voice VLAN : enable
VLAN ID : 5
Priority : 6
Port Mode Tagging VLAN Membership
1 normal tagged no
2 normal tagged no
3 normal tagged no
4 normal tagged no
5 normal tagged no
6 normal tagged no
7 normal tagged no
8 normal tagged no
9 normal tagged no
10 normal tagged no
11 fixed tagged yes
12 fixed tagged yes
13 fixed tagged yes
14 fixed tagged yes
15 fixed tagged yes
16 fixed tagged yes
17 fixed tagged yes
18 fixed tagged yes
19 fixed tagged yes
20 fixed tagged yes
21 forbidden tagged no
22 forbidden tagged no
23 forbidden tagged no
24 forbidden tagged no
25 forbidden tagged no
26 forbidden tagged no
27 forbidden tagged no
28 forbidden tagged no
