Ethernet Switch CLI Reference Guide
27
CHAPTER 5
ARP Commands
Use these commands to look at IP-to-MAC address mapping(s).
5.1 Command Summary
The following section lists the commands for this feature.
Table 12 arp Command Summary
COMMAND DESCRIPTION M P
arp aging-time <60-1000000> Sets how long dynamically learned ARP entries remain in the
ARP table before they age out (and must be relearned).
C13
arp name <name> ip <ip-address>
mac <mac-addr> vlan <vlan-id>
interface port-channel <port-
list>
Creates a static ARP entry which will not age out. C 13
arp name <name> ip <ip-address>
mac <mac-addr> vlan <vlan-id>
interface port-channel <port-
list> inactive
Creates a static ARP entry but disables it. C 13
no arp ip <ip-address> mac <mac-
addr> vlan <vlan-id>
Deletes a static ARP entry from the ARP table. C 13
no arp ip <ip-address> mac <mac-
addr> vlan <vlan-id> inactive
Enables the specified static ARP entry. C 13
show ip arp Displays the ARP table. E 3
clear ip arp Removes all of the dynamic entries from the ARP table. E 13
clear ip arp interface port-
channel <port-list>
Removes the dynamic entries learned on the specified port. E 13
clear ip arp ip <ip-address> Removes the dynamic entries learned with the specified IP
address.
E13
no arp Flushes the ARP table entries. E 13
