Chapter 80 Tech Support Commands
Ethernet Switch CLI Reference Guide
295
This example sets the CPU threshold to 80 and time to 5. Then uses the command show
logging to see the log.
sysname# config <cr>
sysname(config)#
sysname(config)# tech-support cpu 80 keep 5 <cr>
sysname (config)#
sysname(config)# exit <cr>
sysname#
sysname# show logging
1 Jan 01 02:52:55 IN authentication: CLI user admin login
2 Jan 01 02:52:54 NO authentication: Console authentication failure
[username: ]
3 Jan 01 00:01:20 NO system: System cold start
4 Jan 01 00:01:20 AL system: System has reset without management
command
5 Jan 01 00:01:00 IN system: CPU utilization is over 80 and keep 5
second, driver count = 0.
6 Jan 01 00:01:00 IN system: CPU utilization is over 80 and keep 5
second, driver count = 0.
7 Jan 01 00:01:00 IN system: CPU utilization is over 80 and keep 5
second, driver count = 0.
8 Jan 01 00:00:55 IN authentication: CLI user admin login
9 Jan 01 00:01:19 NO system: System cold start
10 Jan 01 00:01:19 AL system: System has reset without management
command
11 Jan 01 00:01:00 IN system: CPU utilization is over 80 and keep 5
second, driver count = 0.
12 Jan 01 00:01:00 IN system: CPU utilization is over 80 and keep 5
second, driver count = 0.
13 Jan 01 00:01:00 IN system: CPU utilization is over 80 and keep 5
second, driver count = 0.
14 Jan 01 00:46:09 DE interface: Port 43 link down
15 Jan 01 00:45:31 DE interface: Port 48 link down
16 Jan 01 00:45:26 DE interface: Port 36 link down
17 Jan 01 00:45:25 DE interface: Port 26 link down
18 Jan 01 00:45:21 DE interface: Port 43 link up
19 Jan 01 00:45:21 DE interface: Port 36 link up
-- more --, next page: Space, continue: c, quit: ESC
