Chapter 24 Green Ethernet Commands
Ethernet Switch CLI Reference Guide
98
The following example shows how to configure short reach if the Switch supports short reach
per port
The following example shows the display for short reach if the Switch supports short reach per
port and showing the status
sysname# configure
sysname(config)# green-ethernet short-reach
sysname# configure
sysname(config)# interface port-channel 1-4
sysname(config-interface)# green-ethernet short-reach
sysname# show green-ethernet short-reach
Global configuration : Enable
Port Config Status
---- ----------- --------------
1 Enable Low power
2 Disable -
3 Enable Unsupported
4 Enable Normal
