Chapter 24 Green Ethernet Commands
Ethernet Switch CLI Reference Guide
97
Auto power down
• Normal means auto power down has not reduced the power on this link
• Power down means auto power down has reduced the power on this link
• Unsupported means the Switch cannot display the status.
• - means auto power down is not enabled
Short reach
• Normal means short reach has not reduced the power on this link
• Low power means short reach has reduced the power on this link
• Unsupported means the Switch cannot display the status.
• - means short reach is not enabled
sysname# configure
sysname(config)# green-ethernet eee
sysname(config)# green-ethernet short-reach
sysname(config)# green-ethernet auto-power-down
sysname(config)# interface port-channel 1-4
sysname(config-interface)# green-ethernet eee
sysname(config-interface)# green-ethernet auto-power-down
sysname(config-interface)# exit
sysname(config)# exit
sysname# show green-ethernet eee
EEE globally configuration : Enable
Port Port status Config Status
---- --------------- ------- ---------
1 100M/F Enable Active
2 Down Enable Inactive
3 100M/F Enable Unsupported
4 Down Disable -
sysname# show green-ethernet auto-power-down
Auto Power Down globally configuration : Enable
Port Config Status
---- ------- ----------
1 Enable Power down
2 Enable Normal
3 Enable Unsupported
4 Disable -
sysname# show green-ethernet short-reach
Short Reach globally configuration : Enable
sysname#
