Chapter 85 VLAN Commands
Ethernet Switch CLI Reference Guide
308
The following table describes the labels in this screen.
This example enables ingress checking on ports 1-5.
Table 196 show vlan
LABEL DESCRIPTION
The Number of VLAN This field displays the number of VLANs on the Switch.
Idx. This field displays an entry number for each VLAN.
VID This field displays the VLAN identification number.
Status This field displays how this VLAN was added to the Switch.
Dynamic: The VLAN was added via GVRP.
Static: The VLAN was added as a permanent entry
Other: The VLAN was added in another way, such as Multicast VLAN
Registration (MVR).
Elap-Time This field displays how long it has been since a dynamic VLAN was
registered or a static VLAN was set up.
TagCtl This field displays untagged and tagged ports.
Untagged: These ports do not tag outgoing frames with the VLAN ID.
Tagged: These ports tag outgoing frames with the VLAN ID.
sysname (config)# interface port-channel 1-5
sysname (config-vlan)# ingress-check
