Chapter 83 Trunk Commands
Ethernet Switch CLI Reference Guide
301
This example shows the current LACP settings.
The following table describes the labels in this screen.
Member Number This field shows the number of ports in the trunk.
Member This field is displayed if there are ports in the trunk.
This field displays the member port(s) in the trunk.
sysname# show lacp
AGGREGATOR INFO:
ID: 1
[(0000,00-00-00-00-00-00,0000,00,0000)][(0000,00-00-00-00-00-00
-->,0000,00,0000)]
LINKS :
SYNCS :
ID: 2
[(0000,00-00-00-00-00-00,0000,00,0000)][(0000,00-00-00-00-00-00
-->,0000,00,0000)]
LINKS :
SYNCS :
ID: 3
[(0000,00-00-00-00-00-00,0000,00,0000)][(0000,00-00-00-00-00-00
--> ,0000,00,0000)]
LINKS :
SYNCS :
Table 191 show lacp
LABEL DESCRIPTION
ID This field displays the trunk ID to identify a trunk group, that is, one logical
link containing multiple ports.
[(0000,00-00-00-00-00-
00,0000,00,0000)]
This field displays the system priority, MAC address, key, port priority, and
port number.
LINKS In some switches this displays the ports whose link state are up.
In other switches this displays the ports which belong to this trunk group.
SYNCS These are the ports that are currently transmitting data as one logical link in
this trunk group.
Table 190 show trunk (continued)
LABEL DESCRIPTION
