![Zyxel XS3700-24 [299/371] Trunk commands](/views2/1168986/page299/bg12b.png)
Ethernet Switch CLI Reference Guide
299
CHAPTER 83
Trunk Commands
Use these commands to logically aggregate physical links to form one logical, higher-
bandwidth link. The Switch adheres to the IEEE 802.3ad standard for static and dynamic
(Link Aggregate Control Protocol, LACP) port trunking.
Different models support different numbers of trunks (T1, T2, ...). This chapter
uses a model that supports six trunks (from T1 to T6).
83.1 Command Summary
The following section lists the commands for this feature.
Table 188 trunk Command Summary
COMMAND DESCRIPTION M P
show trunk Displays link aggregation information. E 3
trunk <T1|T2|T3|T4|T5|T6> Activates a trunk group. C 13
no trunk <T1|T2|T3|T4|T5|T6> Disables the specified trunk group. C 13
trunk <T1|T2|T3|T4|T5|T6>
criteria <src-mac|dst-mac|src-
dst-mac|src-ip|dst-ip|src-dst-
ip>
Sets the traffic distribution type used for the specified trunk
group.
C13
no trunk <T1|T2|T3|T4|T5|T6>
criteria
Returns the traffic distribution type used for the specified
trunk group to the default (src-dst-mac).
C13
trunk <T1|T2|T3|T4|T5|T6>
interface <port-list>
Adds a port(s) to the specified trunk group. C 13
no trunk <T1|T2|T3|T4|T5|T6>
interface <port-list>
Removes ports from the specified trunk group. C 13
trunk <T1|T2|T3|T4|T5|T6> lacp Enables LACP for a trunk group. C 13
no trunk <T1|T2|T3|T4|T5|T6>
lacp
Disables LACP in the specified trunk group. C 13
trunk interface <port-list>
timeout <lacp-timeout>
Defines LACP timeout period (in seconds) for the specified
port(s).
lacp-timeout: 1 or 30
C13
