Ethernet Switch CLI Reference Guide
205
CHAPTER 53
OSPF Commands
This chapter explains how to use commands to configure the Open Shortest Path First (OSPF)
routing protocol on the Switch.
53.1 OSPF Overview
OSPF (Open Shortest Path First) is a link-state protocol designed to distribute routing
information within an autonomous system (AS). An autonomous system is a collection of
networks using a common routing protocol to exchange routing information.
53.2 Command Summary
The following section lists the commands for this feature.
Table 138 OSPF Command Summary
COMMAND DESCRIPTION M P
show ip ospf database Displays OSPF link state database
information.
E3
show ip ospf interface Displays OSPF interface settings. E 3
show ip ospf neighbor Displays OSPF neighbor information. E 3
show ip protocols Displays the routing protocol the Switch is
using and its administrative distance value.
E3
show router ospf Displays OSPF settings. E 3
show router ospf area Displays OSPF area settings. E 3
show router ospf network Displays OSPF network (or interface)
settings.
E3
show router ospf redistribute Displays OSPF redistribution settings. E 3
show router ospf virtual-link Displays OSPF virtual link settings. E 3
interface route-domain <ip-address>/<mask-
bits>
Enters the configuration mode for this
routing domain.
C13
ip ospf authentication-key <key> Specifies the authentication key for OSPF. C 13
no ip ospf authentication-key <key> Disables OSPF authentication in this
routing domain.
C13
ip ospf authentication-same-aa Sets the same OSPF authentication
settings in the routing domain as the
associated area.
C13
