Chapter 22 External Alarm Commands
Ethernet Switch CLI Reference Guide
92
22.2 Command Examples
This example configures and shows the name and status of the external alarm(s).
sysname# configure
sysname(config)# external-alarm 1 name dooropen
sysname(config)# exit
sysname# show external-alarm
External Alarm 1
Status: Not asserted
Name: dooropen
External Alarm 2
Status: Not asserted
Name:
External Alarm 3
Status: Not asserted
Name:
External Alarm 4
Status: Not asserted
Name:
sysname#
