Zyxel XS3700-24 [244/371] Command examples
![Zyxel XS3700-24 [244/371] Command examples](/views2/1168986/page244/bgf4.png)
Chapter 64 RADIUS Commands
Ethernet Switch CLI Reference Guide
244
64.2 Command Examples
This example sets up one primary RADIUS server (172.16.10.10) and one secondary
RADIUS server (172.16.10.11). The secondary RADIUS server is also the accounting server.
radius-accounting host <index>
<ip> [acct-port <socket-number>]
[key [cipher] <key-string>]
Specifies the IP address of the RADIUS accounting server.
Optionally, sets the port number and key of the external
RADIUS accounting server.
index: 1 or 2.
cipher: inform the Switch that the string after the word
"cipher" is an encrypted secret. This is used in password
encryption. To encrypt the password, use the password
encryption command.
key-string: 1-32 alphanumeric characters.
C13
no radius-accounting <index> Resets the specified RADIUS accounting server to its default
values.
C13
Table 153 radius-accounting Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# configure
sysname(config)# radius-server mode index-priority
sysname(config)# radius-server host 1 172.16.10.10
sysname(config)# radius-server host 2 172.16.10.11
sysname(config)# radius-accounting host 1 172.16.10.11
sysname(config)# exit
