Chapter 55 PoE Commands
Ethernet Switch CLI Reference Guide
216
Priority When the total power requested by the PDs exceeds the total PoE power
budget on the Switch, the Switch uses the PD priority to provide power to
ports with higher priority.
Consumption (mW) This field displays the amount of power the Switch is currently supplying to
the PoE-enabled devices connected to this port.
MaxPower(mW) This field displays the maximum amount of power the Switch can supply to
the PoE-enabled devices connected to this port.
Total Power This field displays the total power the Switch can provide to PoE-enabled
devices.
Consuming Power This field displays the amount of power the Switch is currently supplying to
the PoE-enabled devices.
Allocated Power This field displays the total amount of power the Switch has reserved for
PoE after negotiating with the PoE device(s).
Note: If the management mode is set to Consumption, this
field shows NA.
Remaining Power This field displays the amount of power the Switch can still provide for PoE.
Note: The Switch must have at least 16 W of remaining power
in order to supply power to a PoE device, even if the
PoE device requested less than 16 W.
Table 141 show pwr (continued)
LABEL DESCRIPTION
