Chapter 9 Broadcast Storm Commands
Ethernet Switch CLI Reference Guide
40
• 64 DLF packets per second.
sysname# configure
sysname(config)# storm-control
sysname(config)# interface port-channel 1
sysname(config-interface)# broadcast-limit
sysname(config-interface)# broadcast-limit 128
sysname(config-interface)# multicast-limit
sysname(config-interface)# multicast-limit 256
sysname(config-interface)# dlf-limit
sysname(config-interface)# dlf-limit 64
sysname(config)# exit
sysname# show interfaces config 1 bstorm-control
Broadcast Storm Control Enabled: Yes
Port Broadcast|Enabled Multicast|Enabled DLF-Limit|Enabled
1 128 pkt/s|Yes 256 pkt/s|Yes 64 pkt/s|Yes
