Chapter 44 MAC-based VLAN
Ethernet Switch CLI Reference Guide
183
44.3 Command Example:add source MAC address
This example adds a binding source MAC address to a MAC-based VLAN with MAC
address 00:11:22:33:44:55, VLAN ID number 3 and priority level 6..
44.4 Command Example:remove source MAC address
This example deletes a binding source MAC address to a MAC-based VLAN with MAC
address 00:11:22:33:44:55.
sysname(config)# mac-based-vlan name test source-mac 00:11:22:33:44:55 vlan
3 priority 6
sysname(config)
sysname(config)# exit
sysname# show mac-based-vlan
Index Name Source MAC VLAN Priority
1 test 00:11:22:33:44:55 3 6
sysname(config)# no mac-based-vlan source-mac 00:11:22:33:44:55
sysname(config)# exit
