Chapter 72 Stacking Commands
Ethernet Switch CLI Reference Guide
270
Stacking will automatically choose a master Switch in a stack but you can overwrite that by
actively forcing a Switch to become a master Switch using the Stacking force-master
command. This master Switch will have the highest priority over all other stacked Switches
even when they have same priority value.
If two or more Switches have Stacking force-master enabled, then the Switch will
use Stacking priority to determine which is master. If they have the same Stacking
priority, then the Switch with the longest up-time is selected. Uptime is measured in
increments of 10 minutes. The Switch with the higher number of increments is selected. If
they have the same uptime, then the Switch with the lowest MAC address will be the master.
This is the master election priority in a stack system:
1 Stacking force-master
2 Highest Stacking priority
3 Longest System Up Time
4 Lowest MAC Address
Master election occurs when stacking / standalone mode changes or when a
stacking port is temporarily disconnected in stacking mode.
72.2 Command Summary
The following section lists the commands for this feature.
Table 170 stacking Command Summary
COMMAND DESCRIPTION M P
show stacking Shows stacking slot status. E 3
show stacking slot status Shows stacking information on each slot. E 3
show running-config Shows current Switch configuration including stacking slot
summary.
E3
show stacking slot <number> Shows stacking details for the specified slot. E 3
show system-information Shows Switch stacking mode. E 3
Stacking Enables stacking when the Switch is in standalone mode. The
Switch will automatically reboot with a new config01.
C13
no Stacking Enables standalone when the Switch is in stacking mode.
The Switch will automatically reboot with a new config01.
C13
Stacking priority <1-63> Sets switch stacking priority. C 13
Stacking force-master Enables force master mode which makes this Switch the
master in the stack..
C13
no Stacking force-master Disables force master mode. C 13
Stacking slot-id <current slot-
id> renumber auto
Sets selected slot to auto mode. C 13
