Chapter 71 SNMP Server Commands
Ethernet Switch CLI Reference Guide
265
snmp-server trap-community
[cipher] <property>
Sets the trap community. Only for SNMPv2c or lower.
cipher: inform the Switch that the string after the word
"cipher" is an encrypted secret. This is used in password
encryption. To encrypt the password, use the password
encryption command.
C13
snmp-server trap-destination
<ip> [udp-port <socket-number>]
[version <v1|v2c|v3>] [username
<name>]
Sets the IP addresses of up to four SNMP managers (stations
to send your SNMP traps to). You can configure up to four
managers.
C13
no snmp-server trap-destination
<ip>
Deletes the specified SNMP manager. C 13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
snmp trap [options] Enables sending of SNMP traps on this port. The Switch
sends the related traps received on this port to the SNMP
manager.
options: enter the trap type you want to configure here,
such as intrusionlock, loopguard, errdisable, poe, linkup,
linkdown, autonegotiation, lldp, or transceiver-ddm.
C13
no snmp trap [options] Disables sending of SNMP traps on this port. The Switch
sends the related traps received on this port to the SNMP
manager.
options: enter the trap type you want to configure here,
such as intrusionlock, loopguard, errdisable, poe, linkup,
linkdown, autonegotiation, lldp, or transceiver-ddm.
C13
Table 167 snmp-server Command Summary (continued)
COMMAND DESCRIPTION M P
