Chapter 24 Green Ethernet Commands
Ethernet Switch CLI Reference Guide
96
24.2 Command Summary
The following section lists the commands for this feature.
24.3 Green Ethernet Command Example
In this example, the Switch supports EEE and auto power down per port, and short reach
globally. The following are explanations of the Status parameters:
EEE
• Active displays when EEE is enabled and the EEE port is up
• Inactive displays when EEE is enabled but the EEE port is down or the device
connected to this port does not support EEE
• Unsupported means the Switch cannot display the status.
• - means EEE is not enabled
Table 69 green-ethernet Command Summary
COMMAND DESCRIPTION M P
green-ethernet auto-power-down Enables automatic power down on the Switch. E 13
no green-ethernet auto-power-down Disables automatic power down on the Switch. E 13
green-ethernet eee Enables IEEE 802.3az Energy Efficient Ethernet on
the Switch.
E13
no green-ethernet eee Disables eee on the Switch. E 13
green-ethernet short-reach Enables adjusting the transmission power of each
port according to the length of cable attached to
a port on the Switch.
E13
no green-ethernet short-reach Disables short-reach on the Switch. E 13
interface port-channel <port-list> Enters config-interface mode for the specified port(s). C 13
green-ethernet auto-power-down Enables automatic power down on the specified port(s). C 13
no green-ethernet auto-power-
down
Disables automatic power down on the specified port(s). C 13
green-ethernet eee Enables IEEE 802.3az Energy Efficient Ethernet on
the the specified port(s).
C13
no green-ethernet eee Disable IEEE 802.3az Energy Efficient Ethernet on
the the specified port(s).
C13
green-ethernet short-reach Enables adjusting the transmit power of the
specified port(s) according to the length of cable
attached to the port.
C13
no green-ethernet short-reach Disables adjusting the transmit power of the
specified port(s) according to the length of cable
attached to the port.
C13
show green-ethernet auto-power-down Shows automatic power down information. E3
show green-ethernet eee Shows Energy Efficient Ethernet information. E3
show green-ethernet short-reach Shows short reach information. E3
