Chapter 35 IPv6 Commands
Ethernet Switch CLI Reference Guide
145
ipv6 mld snooping-proxy vlan
<vlan-id> upstream interface port-
channel <port-list>
Specifies the upstream (host) port(s) on the Switch. The
port(s) will work as an MLD host to send join or leave
messages when receiving queries from the multicast
router.
C13
ipv6 mld snooping-proxy vlan
<vlan-id> upstream last-listener-
query-interval <1-8387584>
Sets the the amount of time (in miliseconds) between the
MLD group-specific queries sent by an upstream port
when an MLD Done message is received. This value
should be exactly the same as what’s configured in the
connected multicast router.
This value is used to calculate the amount of time an MLD
snooping membership entry (learned only on the
upstream port) can remain in the forwarding table after a
Done message is received.
When an MLD Done message is received, the Switch sets
the entry’s lifetime to be: last-listener-query-
interval x robustness-variable
C13
ipv6 mld snooping-proxy vlan
<vlan-id> upstream query-interval
<1000-31744000>
Sets the amount of time (in miliseconds) between general
query messages sent by the router connected to the
upstream port. This value should be exactly the same as
what’s configured in the connected multicast router.
This value is used to calculate the amount of time an MLD
snooping membership entry (learned only on the
upstream port) can remain in the forwarding table.
When an MLD Report message is received, the Switch
sets the timeout period of the entry to be: query-
interval x robustness-variable + query-max-
response-time
C13
ipv6 mld snooping-proxy vlan
<vlan-id> upstream query-max-
response-time <1000-25000>
Sets the amount of time (in miliseconds) the router
connected to the upstream port waits for a response to an
MLD general query message. This value should be
exactly the same as what’s configured in the connected
multicast router.
This value is used to calculate the amount of time an MLD
snooping membership entry (learned only on the
upstream port) can remain in the forwarding table.
When an MLD Report message is received, the Switch
sets the timeout period of the entry to be: query-
interval x robustness-variable + query-max-
response-time
When an MLD Done message is received, the Switch sets
the entry’s lifetime to be: last-listener-query-
interval x robustness-variable
C13
ipv6 mld snooping-proxy vlan
<vlan-id> upstream robustness-
variable <1-25>
Sets the number of queries. A multicast address entry
(learned only on an upstream port by snooping) is
removed from the forwarding table when there is no
response to the configured number of queries sent by the
router connected to the upstream port. This value should
be exactly the same as what’s configured in the
connected multicast router.
This value is used to calculate the amount of time an MLD
snooping membership entry (learned only on the
upstream port) can remain in the forwarding table.
C13
no ipv6 mld snooping-proxy Disables IPv6 MLD snooping-proxy on the Switch. C 13
no ipv6 mld snooping-proxy
filtering
Disables IPv6 MLD filtering on the Switch. C 13
Table 100 ipv6 mld snooping-proxy Command Summary (continued)
COMMAND DESCRIPTION M P
