Chapter 61 Private VLAN Commands
Ethernet Switch CLI Reference Guide
235
61.2.2 Command Example
This example sets private VLAN 100 as a primary private VLAN, private VLAN 101 as a
community private VLAN and private VLAN 102 as an isolated private VLAN. VLANs 101
and 102 are secondary private VLANs that are associated primary private VLAN 101. Use the
specified show command to display all private VLAN configurations on the switch.
private-vlan association
<secondary-vlan-list>
Primary private VLANs can associate with several
(secondary) Community private VLANs and up to one
(secondary) Isolated private VLAN. Specify a primary private
VLAN, then associate it with a secondary VLAN(s) using this
command.
C13
no private-vlan <primary |
isolated | community>
Disables the VLAN as a Primary, Isolated or Community
VLAN.
C13
no private-vlan association Removes all association between the primary VLAN and
secondary VLANs.
C13
no private-vlan association
<secondary-vlan-list>
Removes association between the primary VLAN and the
specified secondary VLAN(s).
C13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
private-vlan mode
<promiscuous | isolated |
community> association
<vlan-id> dot1q <tagged |
untagged>
Configures PVLAN on a port. Set the associated PVLAN ID,
type of private VLAN and specify whether outgoing frames
from this port are tagged or not.
C13
no private-vlan mode Removes PVLAN mode configuration. C 13
show vlan private-vlan Displays the settings and status of all private VLAN rules on
the Switch.
E3
show vlan private-vlan <vlan-id> Displays the settings and staus of the specified private VLAN
rule on the Switch.
E3
Table 148 private-vlan Command Summary (continued)
COMMAND DESCRIPTION M P
