![Zyxel XS3700-24 [28/371] Command examples](/views2/1168986/page28/bg1c.png)
Chapter 5 ARP Commands
Ethernet Switch CLI Reference Guide
28
5.2 Command Examples
This example creates a static ARP entry and shows the ARP tahle on the Switch.
The following table describes the labels in this screen.
sysname# config
sysname(config)# arp name test ip 192.168.1.99 mac 00:c5:d8:01:23:45 vlan
1 interface port-channel 3
sysname(config)# exit
sysname# show ip arp
Index IP MAC VLAN Port Age(s) Type
1 192.168.1.1 00:19:cb:37:00:49 1 CPU 0 static
2 192.168.1.99 00:c5:d8:01:23:45 1 3 0 static
3 192.168.2.1 00:19:cb:37:00:49 465 CPU 0 static
sysname#
Table 13 show ip arp
LABEL DESCRIPTION
Index This field displays the index number.
IP This field displays the learned IP address of the device.
MAC This field displays the MAC address of the device.
VLAN This field displays the VLAN to which the device belongs.
Port This field displays the number of the port from which the IP address was learned.
CPU indicates this IP address is the Switch’s management IP address.
Age(s) This field displays how long the entry remains valid.
Type This field displays how the entry was learned.
dynamic: The Switch learned this entry from ARP packets.
