Ethernet Switch CLI Reference Guide
186
CHAPTER 46
MAC Forward Commands
Use these commands to configure static MAC address forwarding.
Use the mac commands to look at the current mac-forward settings. See
Chapter 42 on page 178.
46.1 Command Summary
The following table describes user-input values available in multiple commands for this
feature.
The following section lists the commands for this feature.
Table 123 mac-forward User-input Values
COMMAND DESCRIPTION
name 1-32 alphanumeric characters
Table 124 mac-forward Command Summary
COMMAND DESCRIPTION M P
mac-forward name <name> mac
<mac-addr> vlan <vlan-id>
interface <interface-id>
Configures a static MAC address forwarding rule. C 13
no mac-forward mac <mac-addr>
vlan <vlan-id> interface
<interface-id>
Removes the specified MAC forwarding entry, belonging to a
VLAN group forwarded through an interface.
C13
mac-forward name <name> mac
<mac-addr> vlan <vlan-id>
interface <interface-id>
inactive
Disables a static MAC address forwarding rule. C 13
no mac-forward mac <mac-addr>
vlan <vlan-id> interface
<interface-id> inactive
Enables the specified MAC address, belonging to a VLAN
group forwarded through an interface.
C13
