Ethernet Switch CLI Reference Guide
297
CHAPTER 82
Time Range Commands
82.1 About Time Range
You can set a time range for time-oriented features such as Classifier ACL (Access Control
List) rule which categorizes data packets into different network traffic flows. The advantage
of the time range feature is that it allows you to schedule the active time of configurations.
Time range can be configured in two ways - Absolute and Periodic. Absolute is a fixed
time range with a start and end time. Periodic is recurrence of a time range and doesn’t
have an end time.
82.2 Command Summary
The following section lists the commands for this feature.
Command Examples
Table 187 time-range Command Summary
COMMAND DESCRIPTION M P
show time-range <name> Displays details on the named rule. C 3
time-range <name> [ absolute
start <hh:mm> <1-31> <jan-dec>
<1970-2037> end <hh:mm> <1-31>
<jan-dec> <1970-2037>
Creates an absolute time-range rule that has a set start and
end time and date (absolute). name is the name of the time-
range rule.
E13
time-range <name> [ periodic <[
<monday|tuesday|wednesday|thurs
day|friday|saturday|sunday><hh:
mm> to
monday|tuesday|wednesday|thursd
ay|friday|saturday|sunday>
<hh:mm>][<[monday][tuesday][wed
nesday][thursday][friday][satur
day][sunday]|daily|weekdays|wee
kend> <hh:mm> to <hh:mm>]
Creates a periodic time-range rule that recurs at the specified
time and day (periodic). name is the name of the time-
range rule.
E13
