Ethernet Switch CLI Reference Guide
77
CHAPTER 17
DiffServ Commands
Use these commands to configure Differentiated Services (DiffServ) on the Switch.
17.1 Command Summary
The following section lists the commands for this feature.
Table 57 diffserv Command Summary
COMMAND DESCRIPTION M P
show diffserv Displays general DiffServ settings. E 3
diffserv Enables DiffServ on the Switch. C 13
no diffserv Disables DiffServ on the Switch. C 13
diffserv dscp <0-63> priority
<0-7>
Sets the DSCP-to-IEEE 802.1q mappings. C 13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
diffserv Enables DiffServ on the port(s). C 13
no diffserv Disables DiffServ on the port(s). C 13
