Chapter 70 Smart Isolation Commands
Ethernet Switch CLI Reference Guide
262
70.3 Command Examples
This example enables smart isolation and displays smart isolation status and information on
the Switch. You should have configured RSTP or MRSTP on the Switch in order to have smart
isolation work by adding the designated port(s) to the isolated port list. You also have created
VLAN 200 and configured a private VLAN rule for VLAN 200 to put ports 3, 4 and 5 in the
isolated port list. In this example, the designated port 7 is added to the isolated port list after
smart isolation is enabled.
The following table describes the labels in this screen.
sysname# configure
sysname(config)# spanning-tree mode rstp
sysname(config)# spanning-tree
sysname(config)# spanning-tree priority 32768
sysname(config)# spanning-tree 3-5, 7-8
sysname(config)# vlan 200
sysname(config-vlan)# fixed 3-5, 7-8
sysname(config-vlan)# untagged 3-5, 7-8
sysname(config-vlan)# exit
sysname(config)# private-vlan name pvlan-200 vlan 200 promiscuous-port 7-8
sysname(config)# smart-isolation
sysname(config)# exit
sysname# show smart-isolation
smart isolation enable
Private VLAN:
Original VLAN:
VLAN 200
isolated 3-5
promiscuous 7-8
Smart Isolated VLAN:
VLAN 200
isolated 3-5,7
promiscuous 8
sysname#
Table 165 show smart-isolation
LABEL DESCRIPTION
Port isolation This section is available only when you have configured port isolation on
the Switch.
The following fields display the port isolation information before and after
smart isolation is enabled.
original isolated ports This field displays the isolated port list before smart isolation is enabled.
smart isolated ports This field displays the isolated port list after smart isolation is enabled.
Private VLAN This section is available only when you have configured private VLAN on
the Switch.
The following fields display the private VLAN information before and after
smart isolation is enabled.
