Zyxel XS3700-24 [293/371] Command summary
![Zyxel XS3700-24 [293/371] Command summary](/views2/1168986/page293/bg125.png)
Ethernet Switch CLI Reference Guide
293
CHAPTER 80
Tech Support Commands
80.1 Tech-Support Overview
The Tech-Support feature is a log Enhancement tool that logs useful information such as CPU
utilization history, memory and Mbuf (Memory Buffer) information and crash reports for issue
analysis that’s collected by customer support should you have difficulty with your Switch. The
Tech Support Command Line Interface eases your effort in obtaining these reports. Type
show tech-support command to see the log reports.
80.2 Command Summary
The following section lists the commands for this feature.
Table 185 Tech Support Command Summary
COMMAND DESCRIPTION M P
show tech-support Shows all tech-support log reports. E 13
show tech-support cpu Shows CPU history log. The log report holds 7 days of CPU
log data and is stored in volatile memory (RAM). The data is
lost if the Switch is turned off or in event of power outage.
After 7 days, the logs wrap around and new ones and replace
the earliest ones.
E13
show tech-support memory Shows the last memory session log before the Switch is
turned off or in event of power outage.
E13
show tech-support mbuf Shows the mbuf that is higher than the threshold. Default
mbuf value is 50.
E13
show tech-support crash Shows the last crash log before the Switch is turned off or in
event of power outage.
E13
tech-support cpu <threshold>
keep <time>
Sets the CPU threshold and time value for CPU utilization
history report. Default CPU value is 80 and time 5.
cpu threshold: a number between and including 50 and
100.
time: a number between and including 5 to 60.
C13
tech-support mbuf <threshold> Sets the Memory Buffer threshold for mbuf report.
mbuf threshold: a number between and including 50 to
100.
C13
