Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
169
This example shows remote Switch (the Switch connected to the port on the Switch you’re
accessing) LLDP information.
The following table describes the labels in this screen.
Link Aggregation This displays the capability, status, and port ID.
Max Frame Size This displays the maximum frame size on this port.
sysname# show lldp info remote interface port-channel 2
LLDP Remote Device Information Detail:
Local Port: 2
Chassis ID Subtype: mac-address
Chassis ID: 00:19:cb:00:00:02
Port ID Subtype: local-assigned
Port ID: 47
Time To Live: 120
Extended TLV Info 802.1 OUI (hex value) = 00-80-c2
-Port VLAN ID
-ID: 1
-DCBX Application Priority
ether-type: fcoe Priority: 2
-DCBX ETS Configuration
-Willing Bit: False
-Max Traffic Classes: 3
-Priority-Group 7: Strict-priority, Priority-list:-
-Priority-Group 6: Strict-priority, Priority-list:-
-Priority-Group 5: Strict-priority, Priority-list:-
-Priority-Group 4: Strict-priority, Priority-list:-
-Priority-Group 3: Strict-priority, Priority-list:-
-Priority-Group 2: Strict-priority, Priority-list:7
-Priority-Group 1: ETS Bandwidth 50%, Priority-list:3-6
-Priority-Group 0: ETS Bandwidth 50%, Priority-list:0-2
-DCBX PFC Configuration
-Willing Bit: True
-PFC capability: 8
-Priority enable list: 0-2
Extended TLV Info 802.3 OUI (hex value) = 00-12-0f
-Max Frame Size
-Frame Size: 1518
--------------------------------------------------
sysname#
Table 113 Remote Switch LLDP information
LABEL DESCRIPTION
LLDP Remote Device
Information Detail
This contains the following information:
Local Port This is the local port number which receives the LLDPDU from the remote
Switch.
Chassis ID Subtype This displays how the chassis of the remote Switch is identified.
Chassis ID This displays the chassis ID of the remote Switch. The chassis ID is
identified by the chassis ID subtype.
Table 112 Local Switch LLDP information on a port (continued)
LABEL DESCRIPTION
