Chapter 34 IP Source Binding Commands
Ethernet Switch CLI Reference Guide
132
The following table describes the labels in this screen.
Table 91 show ip source binding
LABEL DESCRIPTION
MacAddress This field displays the source MAC address in the binding.
IpAddress This field displays the IP address assigned to the MAC address in the
binding.
Lease This field displays how many days, hours, minutes, and seconds the
binding is valid; for example, 2d3h4m5s means the binding is still valid for
2 days, 3 hours, 4 minutes, and 5 seconds. This field displays infinity if the
binding is always valid (for example, a static binding).
Type This field displays how the switch learned the binding.
static: This binding was learned from information provided manually by an
administrator.
VLAN This field displays the source VLAN ID in the binding.
Port This field displays the port number in the binding. If this field is blank, the
binding applies to all ports.
