Ethernet Switch CLI Reference Guide
213
CHAPTER 55
PoE Commands
Use these commands to configure Power over Ethernet (PoE). These are applicable for PoE
models only.
55.1 Command Summary
The following section lists the commands for this feature.
Table 140 pwr Command Summary
COMMAND DESCRIPTION M P
show pwr Displays information about port power consumption and
Power over Ethernet (PoE). Only available on models
with the PoE feature.
E3
show poe-status This command is available for PoE models only.
Displays information about Power over Ethernet (PoE)
availability and usage.
E0
pwr interface <port-list> Enables PoE (Power over Ethernet) on the specified
port(s).
C13
pwr interface <port-list> max-power
<1000-33000>
Sets the maximum amount of power the PD could use
from the Switch on the specified port(s).
C13
no pwr interface <port-list> max-
power
Removes the maximum power settings for the specified
port(s). The PD(s) that is connected to the port(s) then
can use power up to the Switch’s total power budget.
C13
pwr interface <port-list> priority
<critical|high|low>
Sets the PD priority on a port to allow the Switch to
allocate power to higher priority ports when the
remaining power is less than the consumed power.
critical > high >low
Note: Available for non-full power models only.
C13
no pwr interface <port-list> Disables PoE (Power over Ethernet) on the specified
port(s).
C13
pwr mibtrap Enables PoE MIB traps on the Switch. Traps are initiated
when the usage reaches the limit set by the
pwr
usagethreshold
command.
C13
no pwr mibtrap Disables PoE MIB traps on the Switch. C 13
