Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
160
LLDP-MED (Link Layer Discovery Protocol for Media Endpoint Devices) is an enhanced
extension to LLDP especially for voice applications. You can use LLDP-MED to advertise
location-based information of emergency calls and/or network policies for voice/video
streaming.
37.2 Command Summary
The following section lists the commands for this feature.
Table 106 lldp Command Summary
COMMAND DESCRIPTION M P
interface port-channel <port-list> Enters config-interface mode for configuring the specified
port(s).
C13
lldp admin-status <disabled|tx-
only|rx-only|tx-rx>
Sets LLDP operating mode.
disabled: the port(s) can’t send or receive LLDP
packets.
tx-only: the port(s) can only send LLDP packets.
rx-only: the port(s) can only receive LLDP packets.
tx-rx: the port(s) can send or receive LLDP packets.
C13
lldp basic-tlv management-
address
Enables the sending of Management Address TLVs on
the port(s).
C13
lldp basic-tlv port-description Enables the sending of Port Description TLVs on the
port(s).
C13
lldp basic-tlv system-
capabilities
Enables the sending of System Capabilities TLVs on the
port(s).
C13
lldp basic-tlv system-
description
Enables the sending of System Description TLVs on the
port(s).
C13
lldp basic-tlv system-name Enables the sending of System Name TLVs on the
port(s).
C13
lldp med location civic [county
<county>] [city <city>]
[division <division>]
[neighbor <neighbor>]
[street <street>]
[leading-street-direction
<value>] [trailing-street-
suffix <value>] [street-suffix
<value>] [house-number <num>]
[house-number-suffix <value>]
[landmark <landmark>]
[additional-location <value>]
[name <value>] [zip-code
<value>] [building <value>]
[unit <value>] [floor <value>]
[room-number <value>]
[place-type <value>]
[postal-community-name <value>]
[post-office-box <value> ]
[additional-code <value>]
Sets civic location information, such as street address
and city name.
C13
