Chapter 93 Additional Commands
Ethernet Switch CLI Reference Guide
331
This example sends Ping requests to an Ethernet device with IP address 172.16.37.254.
The following table describes the labels in this screen.
This example shows the current status of the various alarms in the Switch.
The following table describes the labels in this screen.
sysname# ping 172.16.37.254
Resolving 172.16.37.254... 172.16.37.254
sent rcvd rate rtt avg mdev max min reply from
1 1 100 0 0 0 0 0 172.16.37.254
2 2 100 0 0 0 0 0 172.16.37.254
3 3 100 10 1 3 10 0 172.16.37.254
Table 209 ping
LABEL DESCRIPTION
sent This field displays the sequence number of the ICMP request the Switch
sent.
rcvd This field displays the sequence number of the ICMP response the Switch
received.
rate This field displays the percentage of ICMP responses for ICMP requests.
rtt This field displays the round trip time of the ping.
avg This field displays the average round trip time to ping the specified IP
address.
mdev This field displays the standard deviation in the round trip time to ping the
specified IP address.
max This field displays the maximum round trip time to ping the specified IP
address.
min This field displays the minimum round trip time to ping the specified IP
address.
reply from This field displays the IP address from which the Switch received the ICMP
response.
sysname# show alarm-status
name status suppressAlarm alarmLED
----------------- ------ ------------- --------
VOLTAGE Normal No Off
TEMPERATURE Normal No Off
FAN Normal No Off
POE OVER LOAD Normal No Off
POE SHORT CIRCUIT Normal No Off
POE POWERBOX Normal Yes Off
Table 210 show alarm-status
LABEL DESCRIPTION
name This field displays the name or type of the alarm.
status This field displays the status of the alarm.
Normal: The alarm is off.
Error: The alarm is on.
