Chapter 72 Stacking Commands
Ethernet Switch CLI Reference Guide
273
Use these commands to then see the stacking status of the stack, see details of the slots in the
stack and see details of an individual slot.
sysname# show stacking
Slot Id Type Status MAC address Role
------- ------------ ------ ----------------- ------
*1 XGS3700-48HP active 00:19:cb:00:00:02 master
2 - - - -
3 - - - -
4 - - - -
5 - - - -
6 - - - -
7 - - - -
8 - - - -
Stacking Topology:Chain
sysname#
sysname# show stacking slot status
Slot Name Status Up Time Version(Running/Flash1/Flash2)
---- ------------ -------- ----------- ------------------------------
*1 XGS3700-48HP active 68:20:57 V4.20(AAGF.0)b4
V4.20(AAGF.0)b4
V4.10(AAGF.5)b1
2 inactive
3 inactive
4 inactive
5 inactive
6 inactive
7 inactive
8 inactive
sysname#
sysname# show stacking slot 1
Stacking Slot 1 Information
Stacking : active
Role : master
Force Master Mode : active
Priority : 63
Slot ID after reboot : 1
Stacking Status : active
Master Capable : auto
Stacking MAC Address : 00:19:cb:00:00:02
Stacking-channel 1 : down
Stacking-channel 2 : down
Stacking Up Time : 68:19:41
ZyNOS Version
Running : V4.20(AAGF.0)b4
Flash 1 : V4.20(AAGF.0)b4
Flash 2 : V4.10(AAGF.5)b1
sysname#
