Chapter 93 Additional Commands
Ethernet Switch CLI Reference Guide
337
This example displays run-time SFP (Small Form Facter Pluggable) parameters on port 21 on
the
Switch. You can also see the alarm and warning threasholds for temperature, voltage,
transmission bias, transmission and receiving power as shown.
This example displays the firmware version the Switch is currently using..
This example runs an internal loopback test on ports 3-6.
This example displays route information to an Ethernet device with IP address
192.168.1.100.
sysname# show interface transceiver 21
Transceiver Information
Port : 21 (SFP)
Vendor : ZyXEL
Part Number : SFP-LX-10-D
Series Number : S081133000074
Revision : V1.0
Date Code : 2008-08-11
Transceiver : 1000BASE-LX
++ : high alarm, + : high warn, - : low warn, -- : low alarm.
Current High ALarm High Warn Low Warn Low Alarm
Threshold Threshold Threshold Threshold
-------------- ----------- ------------ ----------- ----------- -----------
Temperature(C) ++ 38.00 -1.00 75.00 5.00 0.00
Voltage(V) 3.36 3.50 3.45 3.15 3.10
Tx Bias(mA) 14.53 100.05 90.04 7.00 6.00
Tx Power(dBm) -5.80 -2.99 -3.49 -8.96 -9.50
Rx Power(dBm) + -3.36 -2.99 -3.49 -20.50 -21.02
sysname#
sysname# show version
Current ZyNOS version: V3.80(BBA.3)b1 | 04/17/2008
sysname# test interface port-channel 3-6
Testing internal loopback on port 3 :Passed!
Ethernet Port 3 Test ok.
Testing internal loopback on port 4 :Passed!
Ethernet Port 4 Test ok.
Testing internal loopback on port 5 :Passed!
Ethernet Port 5 Test ok.
Testing internal loopback on port 6 :Passed!
Ethernet Port 6 Test ok.
sysname> traceroute 192.168.1.100
traceroute to 192.168.1.100, 30 hops max, 40 byte packet
1:192.168.1.100 (10 ms) (10 ms) (0 ms)
traceroute done:
sysname>
