Chapter 72 Stacking Commands
Ethernet Switch CLI Reference Guide
271
72.3 Command Examples
Use show system-information to show current Switch stacking mode.
Use the following procedure to create a stack:
1 Select a Switch to be the master. Change its mode to stacking mode. You will see a
message asking you to confirm the change. Press [Y] to confirm and the Switch will
reboot automatically using a new config01.
2 After reboot completes, the master LED will turn on.
3 Force the Switch to be master, configure stacking priority to a high value, such as 63 and
set its slot ID to 1.
Stacking slot-id <current slot-
id> renumber <new slot-id>
Sets selected slot to new slot ID. C 13
reload stacking-default Resets all configurations done since the change to stacking
mode except username and password back to the original
settings.
E13
Table 170 stacking Command Summary (continued)
COMMAND DESCRIPTION M P
sysname# show system-information
Product Model : XGS3700-48HP
System Name : XGS3700
System Mode : Standalone
System Contact :
System Location :
System up Time : 67:58:37 (e965d83 ticks)
Ethernet Address : 00:19:cb:00:00:02
Bootbase Version : V1.00 | 03/27/2013
ZyNOS F/W Version : V4.20(AAGF.0)b4 | 08/12/2014
Config Boot Image : 1
Current Boot Image : 1
RomRasSize : 6550116
sysname#
sysname# configure terminal
sysname(config)# stacking
System will erase all configuration and reboot. Continue? [y/N]y
< reboot…….>
sysname(config)# stacking force-master
sysname(config)# stacking priority 63
sysname(config)# stacking slot-id 1 renumber 1
