Ethernet Switch CLI Reference Guide
112
CHAPTER 29
IGMP Snooping Commands
Use these commands to configure IGMP snooping on the Switch.
29.1 Command Summary
The following section lists the commands for this feature.
Table 77 igmp-flush Command Summary
COMMAND DESCRIPTION M P
igmp-flush Removes all multicast group information. E 13
Table 78 igmp-snooping Command Summary
COMMAND DESCRIPTION M P
clear igmp-snooping statistics all Removes all multicast statistics of the Switch. E 3
clear igmp-snooping statistics
port
Removes the multicast statistics of the port(s). E 3
clear igmp-snooping statistics
system
Removes the multicast statistics of the Switch. E 3
clear igmp-snooping statistics
vlan
Removes the multicast statistics of the multicast VLAN(s) E 3
igmp-snooping Enables IGMP snooping. C 13
no igmp-snooping Disables IGMP snooping. C 13
igmp-snooping 8021p-priority <0-7> Sets the 802.1p priority for outgoing igmp snooping
packets.
C13
no igmp-snooping 8021p-priority Disables changing the priority of outgoing IGMP control
packets.
C13
igmp-snooping authentication-
timeout <0-3000>
Sets how long the Switch waits before sending the same
access request again if the AAA server rejects the host’s
request to join a multicast group.
C13
no igmp-snooping authentication-
timeout
Resets the authentication timeout value to its default
setting.
C13
igmp-snooping filtering Enables IGMP filtering on the Switch. Ports can only join
multicast groups specified in their IGMP filtering profile.
C13
igmp-snooping filtering profile
<name> start-address <ip> end-
address <ip>
Sets the range of multicast address(es) in a profile.
name: 1-32 alphanumeric characters
C13
no igmp-snooping filtering Disables IGMP filtering on the Switch. C 13
