Chapter 14 Data Center Bridging Commands
Ethernet Switch CLI Reference Guide
64
The following table lists the commands for this feature.
14.2.4 ETS Command Example 1
This is an example where the non-editable default traffic class, ID 0, uses SP queuing. LAN
and SAN traffic uses WFQ queuing with equal weighting of 50 each.
The guaranteed minimum bandwidth for both SAN and LAN traffic is 2.5Gbps with a link
bandwidth of 10Gbps.
Create and name traffic class IDs, with weights for the non-SP traffic type.
Table 43 ets Command Summary
COMMAND DESCRIPTION M P
traffic-class <id> scheduler <sp |
ets <weight>> [name <name>]
Creates a WFQ or SP traffic class with ID, weight and
(optional) name.
C13
no traffic-class <id> Deletes the SP/WFQ traffic class with specified ID. C 13
show traffic-class Shows a summary of traffic class(es) created on the
Switch.
E3
interface port-channel <port-list> Enters config-interface mode for the specified port(s). C 13
ets Enable Enhanced Transmission Selection (ETS) queuing
method. See Chapter 63 on page 239 for other queuing
methods.
C13
ets traffic-class binding <tc-
id0> <tc-id1> <tc-id2> <tc-id3>
<tc-id4> <tc-id5> <tc-id6> <tc-
id7>
Binds priorities to a traffic class(es) on the specified
port(s).
C13
no ets traffic-class binding Resets traffic class binding priorities to default settings
on the specified port(s).
C13
unicast-nonunicast-weight
<weight> <weight>
Sets the unicast to non-unicast traffic weight ratio on the
specified port(s).
C13
Table 44 ETS Example Traffic Classes
TRAFFIC CLASS ID GUARANTEED BANDWIDTH NAME
0SPDefault
1 50 SAN
250LAN
Table 45 ETS Example Traffic Bandwidths
NAME
INCOMING TRAFFIC
BANDWIDTH (GBPS)
GUARANTEED
MINIMUM BANDWIDTH
OUTGOING TRAFFIC
BANDWIDTH (GBPS)
Default 5 5 (SP) 5
SAN 3 (10-5) * (50/(50+50)) =
2.5
2.5
LAN 4 (10-5) * (50/(50+50)) =
2.5
2.5
sysname# configure
sysname(config)# traffic-class 1 scheduler ets 50 name LAN
sysname(config)# traffic-class 2 scheduler ets 50 name SAN
