Zyxel XS3700-24 [330/371] Command examples
![Zyxel XS3700-24 [330/371] Command examples](/views2/1168986/page330/bg14a.png)
Chapter 93 Additional Commands
Ethernet Switch CLI Reference Guide
330
93.2 Command Examples
This example checks the cable pairs on ports 1 and 4.
The following table describes the labels in this screen.
sysname# cable-diagnostics 1
Port Channel Pair status Cable length (m) Distance to fault (m)
---- ------- ----------- ---------------- ---------------------
1 pairA Open N/A 0.00
pairB Open N/A 0.00
pairC Open N/A 0.00
pairD Open N/A 0.00
sysname# cable-diagnostics 4
Port Channel Pair status Cable length (m) Distance to fault (m)
---- ------- ----------- ---------------- ---------------------
4 pairA Ok 5.55 N/A
pairB Ok 5.55 N/A
pairC Ok 5.55 N/A
pairD Ok 5.55 N/A
Table 208 Cable-diagnostics
LABEL DESCRIPTION
Port This is the number of the physical Ethernet port on the Switch.
Channel An Ethernet cable usually has four pairs of wires. A 10BASE-T or
100BASE-TX port only use and test two pairs, while a 1000BASE-T port
requires all four pairs.
This displays the descriptive name of the wire-pair in the cable.
Pair status Ok: The physical connection between the wire-pair is okay.
Open: There is no physical connection (an open circuit detected) between
the wire-pair.
Short: There is an short circuit detected between the wire-pair.
Unknown: The Switch failed to run cable diagnostics on the cable
connected this port.
Unsupported: The port is a fiber port or it is not active.
Cable length This displays the total length of the Ethernet cable that is connected to the
port when the Pair status is Ok and the Switch chipset supports this
feature.
This shows N/A if the Pair status is Open or Short. Check the Distance to
fault.
This shows Unsupported if the Switch chipset does not support to show
the cable length.
Distance to fault This displays the distance between the port and the location where the
cable is open or shorted.
This shows N/A if the Pair status is Ok.
This shows Unsupported if the Switch chipset does not support to show
the distance.
