Chapter 82 Time Range Commands
Ethernet Switch CLI Reference Guide
298
The following are some examples of using the time-range commands.
sysname#
sysname# configure terminal
sysname(config)# time-range work absolute start 08:00 1 jan 2015 end
17:30 31 dec 2015
sysname(config)#exit
sysname# show time-range work
Time range work:
Absolute start 08:00 1 January 2015 end 17:30 31 December 2015
sysname(config)# time-range work2 periodic monday 08:00 to friday 17:30
monday 08:00 to friday 17:30
sysname(config)# exit
sysname# show time-range work2
Time range work2:
Periodic Monday 08:00 to Friday 17:30
sysname#
