Zyxel XS3700-24 [296/371] Tftp commands
![Zyxel XS3700-24 [296/371] Tftp commands](/views2/1168986/page296/bg128.png)
Ethernet Switch CLI Reference Guide
296
CHAPTER 81
TFTP Commands
Use these commands to back up and restore configuration and firmware via TFTP.
81.1 Command Summary
The following section lists the commands for this feature.
Table 186 tftp Command Summary
COMMAND DESCRIPTION M P
copy tftp flash <ip> <remote-
file>
Restores firmware via TFTP. E 13
copy tftp config <index> <ip>
<remote-file>
Restores configuration with the specified filename from the
specified TFTP server to the specified configuration file on
the Switch.
index: 1 or 2
Use reload config <1|2> to restart the Switch and use
the restored configuration.
Note: This overwrites the configuration on the
Switch with the file from the TFTP server.
E13
copy tftp config merge <index>
<ip> <remote-file>
Merges configuration with the specified filename from the
specified TFTP server with the specified configuration file on
the Switch.
index: 1 or 2
Use reload config <1|2> to restart the Switch and use
the restored configuration.
Note: This joins the configuration on the Switch
with the one on the TFTP server, keeping
the original configuration file and simply
adding those parts that are different.
E13
copy running-config tftp <ip>
<remote-file>
Backs up running configuration to the specified TFTP server
with the specified file name.
E13
