Chapter 93 Additional Commands
Ethernet Switch CLI Reference Guide
336
This example displays run-time SFP (Small Form Facter Pluggable) parameters on ports 9 (the
first SFP port 0, with an SFP transceiver installed) and 10 (the second SFP port 1, no SFP
transceiver installed) on the
Switch. You can also see the alarm and warning threasholds for
temperature, voltage, transmission bias, transmission and receiving power as shown.
System Location This field displays the geographic location of this Switch. Use the snmp-
server command to configure this. See Chapter 71 on page 264.
System up Time This field displays how long the switch has been running since it last started
up.
Ethernet Address This field displays the MAC address of the Switch.
Bootbase Version This field displays the bootbase version the Switch is running.
ZyNOS F/W Version This field displays the firmware version the Switch is running.
Config Boot Image This field displays whether the Switch is configured to run firmware 1 or 2
when it next starts.
Current Boot Image This field displays whether the Switch is running firmware 1 or 2.
RomRasSize This field displays how much ROM is used.
sysname# show sfp 9-10
SFP : 0
Part Number : SFP-SX-DDM
Series Number : S081113001132
Revision : V1.0
Transceiver : 1000BASE-SX
Temperature(C) Alarm(80.00 ~ 0.00), Warning(75.00 ~ 5.00), Current(38.00)
Voltage(V) Alarm(3.50 ~ 3.10), Warning(3.45 ~ 3.15), Current(3.37)
Tx Bias(mA) Alarm(100.05 ~ 1.00), Warning(90.04 ~ 2.00), Current(5.25)
Tx Power(dBm) Alarm(-2.99 ~ -8.98), Warning(-3.49 ~ -8.48), Current(-6.05)
Rx Power(dBm) Alarm(-2.99 ~ -18.01), Warning(-3.49 ~ -17.39), Current(-4.24)
SFP : 1
Not Available
Table 215 show system-information (continued)
LABEL DESCRIPTION
