Chapter 84 trTCM Commands
Ethernet Switch CLI Reference Guide
304
This examples activates trTCM on the Switch with the following settings :
• Enable trTCM on the Switch
• Enable Diffserv on the Switch
• Set the Switch to inspect the DSCP value of packets (color-aware mode)
• Create a trTCM DSCP profile with the name “abc”, and set DSCP value 1 for green
packets, 2 for yellow packets, 3 for red packets
• Associate the profile “abc” with port 1
• Enable trTCM on port 1
• Enable Diffserv on port 1
• Set the Committed Information Rate (CIR) to 4000 Kpbs
• Set the Peak Information Rate (PIR) to 4500 Kbps
• Display the settings of this example
sysname# config
sysname(config)# trtcm
sysname(config)# diffserv
sysname(config)# trtcm mode color-aware
sysname(config)# trtcm dscp profile abc dscp green 1 yellow 2 red 3
sysname(config)# interface port-channel 1
sysname(config-interface)# trtcm
sysname(config-interface)# diffserv
sysname(config-interface)# trtcm dscp profile abc
sysname(config-interface)# trtcm cir 4000
sysname(config-interface)# trtcm pir 4500
sysname(config-interface)# exit
sysname(config)# exit
sysname # show running-config
Building configuration...
Current configuration:
vlan 1
name 1
normal ""
fixed 1-28
forbidden ""
untagged 1-28
ip address default-management 192.168.1.1 255.255.255.0
exit
trtcm
trtcm mode color-aware
trtcm dscp profile abc dscp green 1 yellow 2 red 3
interface port-channel 1
diffserv
trtcm
trtcm cir 4000
trtcm pir 4500
trtcm dscp profile abc
exit
diffserv
sysname #
