Zyxel XS3700-24 [165/371] Lldp settings on a port
![Zyxel XS3700-24 [165/371] Lldp settings on a port](/views2/1168986/page165/bga5.png)
Chapter 37 Link Layer Discovery Protocol (LLDP) Commands
Ethernet Switch CLI Reference Guide
165
The following table describes the labels in this screen.
This example shows LLDP settings on a port.
The following table describes the labels in this screen.
Table 107 Switch LLDP settings
LABEL DESCRIPTION
Active This displays whether LLDP is enabled on the Switch. It is disabled by
default.
Transmit Interval This displays how long the Switch waits before sending LLDP packets.
Transmit Hold This displays the time-to-live (TTL) multiplier of LLDP frames. The device
information on the neighboring devices ages out and is discarded when its
corresponding TTL expires. The TTL value is to multiply the TTL multiplier
by the LLDP packets transmitting interval.
Transmit Delay This displays the delay (in seconds) between the successive LLDP PDU
transmissions initiated by value or status changes in the Switch MIB.
Reinitialize Delay This displays the number of seconds for LLDP to wait before initializing on
a port.
sysname# show lldp config interface port-channel 2
LLDP Port Configuration:
Port AdminStatus Notification BasicTLV Dot1TLV Dot3TLV
2 tx-rx Disable ----- --EFA ----
Basic TLV Flags: (P)Port Description, (N)System Name, (D)System Description
(C)System Capabilities, (M)Management Address
802.1 TLV Flags: (P)Port & Protocol VLAN ID, (V)Port VLAN ID
(E)DCBX ETS Configuration, (F)DCBX PFC Configuration
(A)DCBX Application Priority Configuration
802.3 TLV Flags: (L)Link Aggregation, (M)MAC/PHY Configuration/Status
(F)Maximum Frame Size, (P)Power Via MDI
sysname#
Table 108 LLDP settings on a port
LABEL DESCRIPTION
Port This displays the port number with this LLDP configuration.
AdminStatus This displays whether LLDP transmission and/or reception is allowed on
this port.
Notification This displays whether LLDP notification is enabled on this port.
BasicTLV This shows which Basic TLC flags are enabled on this port. For example,
‘N’ is System Name.
Dot1TLV This shows which 802.1 TLV flags are enabled on this port. For example,
‘V’ is Port VLAN ID.
Dot3TLV This shows which 802.3 TLV flags are enabled on this port. For example, ‘L’
is Link Aggregation.
BasicTLV Flags The Basic TLV Flags are (P) Port Description, (N) System Name, (D)
System Description, (C) System Capabilities, and (M) Management
Address.
