Chapter 72 Stacking Commands
Ethernet Switch CLI Reference Guide
274
Use these commands to see the stacking mode on a Switch.
sysname# show running-config
Building configuration...
Current configuration:
;; slot 1 type XGS3700-48HP
stacking force-master
vlan 1
name 1
fixed 1/1-1/50
forbidden ""
untagged 1/1-1/50
ip address 172.23.30.223 255.255.0.0
exit
interface route-domain 172.23.30.223/16
exit
ip address 192.168.0.1 255.255.0.0
ip address default-gateway 192.168.0.254
service-control http 80 255
service-control console 255
service-control telnet 23 255
sysname#
sysname# show system-information
Product Model : XGS3700-48HP
System Name : XGS3700
System Mode : Stacking
System Contact :
System Location :
System up Time : 67:58:37 (e965d83 ticks)
Ethernet Address : 00:19:cb:00:00:02
Bootbase Version : V1.00 | 03/27/2013
ZyNOS F/W Version : V4.20(AAGF.0)b4 | 08/12/2014
Config Boot Image : 1
Current Boot Image : 1
RomRasSize : 6550116
sysname#
