Ethernet Switch CLI Reference Guide
315
CHAPTER 88
VLAN Port Isolation Commands
Use these commands to configure VLAN port isolation on the Switch. VLAN port isolation
allows each port to communicate only with the CPU management port and the uplink ports,
but not to communicate with each other.
88.1 Command Summary
The following section lists the commands for this feature.
Table 200 vlan1q port-isolation Command Summary
COMMAND DESCRIPTION M P
show vlan1q port-isolation Displays port isolation settings. E 3
vlan1q port-isolation Enables VLAN port isolation. C 13
no vlan1q port-isolation Disables VLAN port isolation. C 13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
no vlan1q port-isolation Enables VLAN port isolation on the port(s). C 13
vlan1q port-isolation Disables VLAN port isolation on the port(s). C 13
