Chapter 14 Data Center Bridging Commands
Ethernet Switch CLI Reference Guide
65
This command shows traffic class.
Next, configure a port for traffic class(es) and bind priorities to traffic classes on a port. In the
next example, we configure port 1 and bind priorities 0, 1 and 2 to traffic class 2 (LAN), 3, 4,
5 and 6 to class 1 (SAN) and 7 to class 0, the default traffic class.
14.2.5 Application Priority
Use the application priority command to assign a priority to all FCoE traffic on a switch.
The following table lists the commands for this feature.
switch# show traffic-class
Traffic Class Profile Configuration:
Traffic Class ID Scheduler Weight Name
---------------- --------- ------ -------------------------------
0 sp - Default
1 ets 50 LAN
2 ets 50 SAN
Table 46 ETS Example Priority Traffic Class ID Mapping
PRIORITY TRAFFIC CLASS ID NAME
02LAN
12LAN
22LAN
3 1 SAN
4 1 SAN
5 1 SAN
6 1 SAN
7 0 Default
sysname(config)# interface port-channel 1
sysname(config-interface)# ets
sysname(config-interface)# ets traffic-class binding 2 2 2 1 1 1 1 0
sysname(config-interface)# unicast-nonunicast-weight 100 100
sysname(config-interface)# exit
Table 47 application priority Command Summary
COMMAND DESCRIPTION M P
lldp dcbx application <ether-
type><fcoe> priority <0-7>
Assigns the specified priority value to all FCoE traffic on
the Switch.
C13
no lldp dcbx application <ether-
type > <fcoe>
Clears priority value for all FCoE traffic on the Switch. C 13
