![Zyxel XS3700-24 [68/371] Dhcp commands](/views2/1168986/page68/bg44.png)
Ethernet Switch CLI Reference Guide
68
CHAPTER 15
DHCP Commands
Use these commands to configure DHCP features on the Switch.
• Use the dhcp option commands to configure DHCP Option 82 profiles.
• Use the dhcp relay commands to configure DHCP relay for specific VLAN.
• Use the dhcp smart-relay commands to configure DHCP relay for all broadcast
domains.
• Use the dhcp server commands to configure the Switch as a DHCP server. (This
command is available on a layer 3
Switch only.)
15.1 Command Summary
The following section lists the commands for this feature.
Table 50 dhcp option Command Summary
COMMAND DESCRIPTION M P
dhcp option profile <name>
[ circuit-id [slot-port] [vlan]
[hostname] [string <string>] ] [
remote-id [mac] [string
<string>] ]
Creates a DHCPv4 option 82 profile. C 13
no dhcp option profile <name> Deletes the specified DHCPv4 option 82 profile. C 13
show dhcp option profile Displays DHCP option 82 profile settings. E 3
Table 51 dhcp relay Command Summary
COMMAND DESCRIPTION M P
show dhcp relay <vlan-id> Displays DHCP relay settings for the specified VLAN. E 3
dhcp relay <vlan-id> helper-
address <remote-dhcp-server1>
[<remote-dhcp-server2>]
[<remote-dhcp-server3>]
[option] [information]
Enables DHCP relay on the specified VLAN and sets the IP
address of up to 3 DHCP servers. Optionally, sets the Switch
to add relay agent information and system name.
Note: You have to configure the VLAN before you
configure a DHCP relay for the VLAN. You
have to disable dhcp smart-relay
before you can enable dhcp relay.
C13
