![Zyxel XS3700-24 [187/371] Command summary](/views2/1168986/page187/bgbb.png)
Ethernet Switch CLI Reference Guide
187
CHAPTER 47
MAC Pinning Commands
Use these commands to configure MAC pinning to set a port or multiple ports to have priority
over other ports in MAC address learning. That means when a MAC address (and VLAN ID)
is learned on a MAC-pinning-enabled port, the MAC address will not be learned on any other
port until the aging time for the dynamically learned MAC address in the table expires.
47.1 Command Summary
The following table describes user-input values available in multiple commands for this
feature.
The following section lists the commands for this feature.
Table 125 mac-pinning User-input Values
COMMAND DESCRIPTION
port-list The port number or a range of port numbers that you want to configure.
Possible values range from 1 to the number of ports on your Switch.
Table 126 mac-pinning Command Summary
COMMAND DESCRIPTION M P
mac-pinning Enables MAC pinning on the Switch. C 13
no mac-pinning Disables MAC pinning on the Switch. C 13
interface port-channel <port-
list>
Enters config-interface mode for the specified port(s). C 13
mac-pinning Enables MAC pinning on the specified port(s). C 13
no mac-pinning Disables MAC pinning on the specified port(s). C 13
show mac-pinning Displays MAC pinning settings E 3
