Chapter 31 Interface Commands
Ethernet Switch CLI Reference Guide
122
media-type 10g <SFP+|DAC10G> Sets the media type of the SFP+ module that is attached
to the 10 Gigabit interface.
On the Switch that has a 10 Gigabit interface, such as
the SFP+ slot, you can insert either an SFP+ transceiver
or an SFP+ Direct Attach Copper (DAC). An SFP+ Direct
Attach Copper (DAC) is an SFP+ housing that has no
optical module but uses a fixed-length passive copper
cable assembly, which reduces cost and power
significantly.
C13
name <port-name-string> Sets a name for the port(s).
port-name-string: up to 64 English keyboard
characters
C13
no flow-control Disables flow control on the port(s). C 13
no inactive Enables the port(s) on the Switch. C 13
no intrusion-lock Disables intrusion-lock on a port so that a port can be
connected again after you disconnected the cable.
C13
pvid <1-4094> The default PVID is VLAN 1 for all ports. Sets a PVID in
the range 1 to 4094 for the specified interface.
C13
qos priority <0-7> Sets the quality of service priority for an interface. C 13
speed-duplex <auto|10-half|10-
full|100-half|100-full|1000-
full|1000-auto|10000-
full|40000-full>
Sets the duplex mode (
half or full) and speed (10,
100, 1000, 10000 or 40000 Mbps) of the
connection on the interface. Select
auto (auto-
negotiation) to let the specified port(s) negotiate with a
peer to obtain the connection speed and duplex mode.
C13
no interface <port-num> Resets the port counters for the specified port(s). E 13
show interfaces <port-list> Displays the current interface status for the specified
port(s).
E3
show interfaces config <port-list> Displays current interface configuration for the specified
port(s).
E3
Table 83 interface Command Summary (continued)
COMMAND DESCRIPTION M P
